TIGER

LOW & MEDIUM DUTY AIRLESS SPRAY PAINTING EQUIPMENT

The range  is suitable  for liquids  of medium  viscosities, primers,  finish paints and paints  of medium  viscosity &

particle size

Features -:

Pneumatically sensed Stall free Air Motor
High Flow Rate
Stainless Steel rust proof Hydraulic Body
Easy Maintenance
Ice Free Air Motors
Light and Easy to handle
Compliance to EC Norms

Medium Duty Airless Spray Painting

Type 16.70 16.150 16.275 28.40 30.150 35.70 40.110 45.150 60.70 60.110
Ratio* 16:1 16:1 16:1 28:1 30:1 35:1 40:1 45:1 60:1 60:1
Output Per Cycle 70cc 150cc 275cc 40cc 150cc 70cc 110cc 150cc 70cc 110cc
Air Motor Piston Φ 80mm 125mm 160mm 80mm 160mm 125mm 160mm 200mm 160mm 200mm
Stroke Length 120mm 120mm 120mm 120mm 120mm 120mm 120mm 120mm 120mm 120mm
Recommended Spray Volume@25 cycles per min 1.75ltr 3.75ltr 6.87ltr 1.00ltr 3.75ltr 1.75ltr 2.75ltr 3.75ltr 1.75ltr 2.75ltr
Air Inlet Pressure Max. 8 bar 8 bar 8 bar 6 bar 8 bar 6 bar 8 bar 6 bar 6 bar 6 bar
Output Pressure Max. 128bar 128bar 128bar 168bar 240bar 210bar 320bar 270bar 360bar 360bar
Air Consumption N ltr/min at 25cycles/min 280 600 1100 200 1000 450 1000 1150 850 1150

Automobile
Automotive
Railways Tiger
Railways
Roof Coating
Roofs Coating
bridge construction
Bridges
Barrel Painting 1
Barrel Painting
Pipe Coating Tiger
Pipe Coating
